EAPL 6 Channel Annunciator with Test / Mute / Acknowledge / Reset buttons
Product SpecificationBrand | EAPL |
Voltage (V) | 85 -270 AC / DC or 18-90 AC/DC (Factory Set) |
Number Of Windows | 6 |
Dimensions | 73.5 x 142.5 x 78 mm |
Cut Out | 69 x 141 mm |
Top Window Size | 66 x 27.5mm |
Bottom Window Size | 31.5 x 27.5mm |
Features:
• Sleek, light weight, ABS enclosure
• Super bright, White color SMD, LED for fault indications
• Test / Mute / Acknowledge / Reset (buttons in front and terminals at rear) are available.
• Multiple units terminals can be connected in parallel to achieve more windows
• Each window can be programmed for fault inputs as NO or NC and output as alarm or trip
• Above program can be locked by removing the short link across specified terminals
• Manual RESET and Auto RESET facility available
