The Kusam Meco KM-CVD-11KV is a contact type high voltage detector designed for safe detection of 11kV power frequency voltage on overhead lines and electrical equipment. It is an essential HV detector for linemen, substations, and electrical maintenance teams.
An 11kV contact type high voltage detector confirms the presence of voltage by directly contacting the conductor using an insulated telescopic rod. The KM-CVD-11KV provides both audible and visual indication, ensuring personal safety before starting electrical work.
| Parameter | KM-CVD-11KV |
|---|---|
| Trigger Voltage | 1.5 – 4.0 kV |
| Leakage Current | < 500 μA |
| Sound Intensity | > 70 dB |
| Light Intensity | 50000 LX |
| DC Voltage Test | 10 kV |
| Extended Length | 3 ft 8 in |
| Retracted Length | 1 ft 1 in |
Manufactured by an ISO 9001:2015 certified company, the KM-CVD-11KV ensures safe and reliable detection of live 11kV lines. It is widely used by power utilities and industrial electricians for ensuring work safety.
Yes. It is a contact type high voltage detector that requires physical contact with the conductor using an insulated rod.
Yes. The KM-CVD-11KV is specifically designed for 11kV systems and distribution networks.
Yes. The detector gives both audible and visual alerts when voltage is present.
