Specifications
Detectable Substrate Material : Ferrous metal (iron, steel).
Thickness Range : 0 ~ 80.0mils (0 ~ 2000 micrometers)
Display Resolution : 0.1mils/1 micrometer
Power Supply : Standard 1.5V AAA Size Battery X 2
Dimension : 105(H) x 55(W) x 27(D)mm
Weight : Approx 80 g (including battery)

Features :
• Measures coating thickness on Ferrous base materials.
• Portability and simple one hand operation.
• Select the on-line display for one off MAX/MIN/MAX-MIN/AVG function.
• Fast one point calibration for frequent measuring thickness use.
• 2-point calibration for normal use
• Auto-power off.
• LED Back-light & LCD display Reverse for easy reading.
• Data logging function capacity up to 255 samples.
• Warning beeper triggers by Hi/Lo limit settings.
• µ m/mils user-selective.
• Inch & Metric measurement options.
• Zeroing Plate & Standard Coating Plate.
• Attached with carrying strap.
