Kusam Meco KM-5415 15kV Digital Insulation Resistance Tester (Megohmmeter)

The Kusam Meco KM-5415 Insulation Tester is a powerful 15kV digital insulation resistance tester designed for high-voltage applications in substations, transformers, motors, generators, and HV cables. With an insulation resistance measurement capability up to 50TΩ, the KM-5415 is ideal for preventive maintenance and reliable electrical testing in demanding industrial and utility environments.

Key Features:

• Test voltages: 500V, 1000V, 2500V, 5000V, 10kV, 15kV
• Insulation resistance range: 0.01MΩ to 50TΩ
• Accuracy: ±3%rdg ±5dgt, Resolution: 0.01MΩ
• Large LCD display with gray backlight
• Measures DC/AC voltage, DC current, and capacitance
• Polarization Index (PI) & Absorption Ratio (DAR) measurement
• Data storage up to 500 readings with USB transfer
• Automatic discharge and alarm function for operator safety
• IP54 dustproof, moisture-proof, and shockproof design
• Meets IEC61010-1, IEC61557 safety standards

Technical Specifications (KM-5415):

Applications:

The KM-5415 is widely used in:

• Substations for high-voltage transformer and switchgear testing
• Industrial plants for generator, motor, and cable insulation testing
• Power utilities for preventive maintenance of HV equipment
• Telecom & IT facilities for insulation monitoring

Buy the Kusam Meco KM-5415 insulation tester online at IndiaMeters.in – trusted supplier of high-voltage insulation testers across India.
