Kusam Meco KM-5410 10kV Insulation Tester for Substations
Product Details
Brand: Kusam Meco
MPN: KM-5410
Kusam Meco KM-5410 10kV Digital Insulation Resistance Tester (Megohmmeter)
The Kusam Meco KM-5410 Insulation Tester is a high-voltage 10kV digital insulation resistance tester designed for testing transformers, motors, generators, cables, and substation equipment. With an extended resistance measurement up to 35TΩ, this instrument delivers precision, reliability, and durability in the toughest environments.
Key Features:
- Test voltages: 250V, 500V, 1000V, 2500V, 5000V, 10kV
- Insulation resistance range: 0.01MΩ to 35TΩ
- Accuracy: ±3%rdg ±5dgt, Resolution: 0.01MΩ
- Large backlit LCD display with data review
- Data storage up to 500 readings with USB transfer
- Automatic discharge and alarm functions for safety
- Measures Polarization Index (PI) & Absorption Ratio (DAR)
- Also measures AC/DC voltage, DC current, and capacitance
- IP54 dustproof and moisture-proof protection
- Shockproof design, compliant with IEC safety standards
Technical Specifications (KM-5410):
| Rated Test Voltages | 250V / 500V / 1000V / 2500V / 5000V / 10kV |
| Insulation Resistance Range | 0.01MΩ – 35TΩ |
| Short-Circuit Current | ≥ 6mA |
| Accuracy | ±3%rdg ±5dgt |
| Display | 4-digit LCD with gray backlight |
| Data Storage | 500 groups, with USB interface |
| DC Voltage Range | 0.1V – 1000V (±1.5%) |
| AC Voltage Range | 0.1V – 750V (±1.5%) |
| DC Current Range | 0.01nA – 6mA (±5%) |
| Capacitance Measurement | 10nF – 50µF (±10%) |
| Working Temp / Humidity | -10°C to +50°C, <85%RH |
| Protection | IP54, CAT III 300V |
| Power | 12V rechargeable battery |
| Size / Weight | 240 × 188 × 85 mm / 2.72 kg |
Applications:
The KM-5410 is widely used in:
- Substations for transformer and switchgear insulation testing
- Industrial plants for motors, generators, and cables
- Power utilities for high-voltage preventive maintenance
- Telecom & IT facilities for insulation monitoring
Order the Kusam Meco KM-5410 insulation tester online from IndiaMeters.in – trusted source for industrial test and measurement instruments in India.
📥 Download Kusam Meco Insulation Tester KM-5405 / KM-5410 / KM-5415 Catalogue (PDF)
