Kusam Meco KM-131D is capable of accurate measurement for different materials or parts in industrial production, as well as monitoring pipelines and pressure vessels of production equipment, and corrosion degree of various parts in use. The thickness of any good conductor for ultrasonic waves with top & bottom surfaces parallel to each other, like metal, plastic, ceramic & glass, can be measured with the instrument. For example : aluminum, copper, gold, resin, water, glycerin, etc. The internal particles of cast iron are too big for this instrument.

Electrical Specifications:
• Measuring range : 1.00〜225.0mm
• Data storage : 500
• Operation frequency : 5MHz
• Measurement error : ±(0.5%H+0.05)mm
• Lower limit of pipe measurement : Φ20x3mm (steel)
• Adjustment range of sound speed : 1000〜9999m/s
• Temperature range of operation : 0〜40℃
• Battery : 3 Ni-MH rechargeable batteries of 1.2V
• USB charging : 5V 1A
• Dimensions : 65x146x30mm
• Weight : 130G

Accessories : Sensor 1pc., Coupling agent-1 bottle, Calibration block, Hard carrying case.
